Beginner’s guide to add a toolbar to an iOS iPhone app with a Storyboard

Leave a comment

I’ve been playing around with iPhone apps a little bit. I’m certainly no expert though, I’m still a beginner myself.

A basic task is to add a toolbar with buttons to your application using XCode.

Lots of samples online are using old versions of XCode. Allow me to demonstrate how to add a toolbar to an app, using XCode 4.2 with Storyboards.

Create a new Project

In Xcode, File -> New Project. Choose Single View Application. I named my application com.mattfrear.toolbars.

Add a toolbar

If you can’t see it, choose View -> Navigators -> Show Project Navigator.

If you can’t see it, choose View -> Utilities -> Show Object Library.

Open the MainStoryboard_iPhone.storyboard. Click on the View.

In the Object Library (which should be in a window at the bottom right of your screen), scroll to the bottom and choose Toolbar. Drag it onto the View. Your screen should look like this:

Screen Shot 2013-08-29 at 16.05.42

Wire up the button

Now we need to add some code which will be fired when the button is clicked.

Open ViewController.m. At the end of the file, before the last @end, paste the following:

-(IBAction) buttonClicked
{
    UIAlertView *alert = [[UIAlertView alloc] initWithTitle:@"Hello world"
                                                    message:@"You clicked the button"
                                                   delegate:nil
                                          cancelButtonTitle:@"OK"
                                          otherButtonTitles:nil];
    [alert show];
}

This is the code which will execute when the button is clicked, and it will display a simple Hello World popup.

Our final step is to wire up the button to this method. To make this easier we can use the Assistant Editor.

In Xcode, go View -> Assistant Editors on Right. Then View -> Show Assistant Editor.

If your screen is small, you might want to go View -> Utilities -> Hide Utilities.

The Assistant Editor should have ViewController.h open. In the Assistant Editor toolbar at the top, it should say Automatic > ViewController.h > No Selection. In that toolbar, click on ViewController.h and choose ViewController.m from the dropdown.

Screen Shot 2013-08-29 at 16.30.55

In the main window, click on the toolbar we added to our View, then on our "Item" toolbar button. Now right click it to bring up the "Bar Button Item - Item" menu.
Under Sent Actions, next to selector there is a + button. Click that and then drag it to the buttonClicked method in ViewController.m.

Screen Shot 2013-08-29 at 16.34.40 (2)

Hooray! Now our toolbar button is wired up to the method. Let's run our app to test it.

In XCode's toolbar, next to the big Run and Stop button you should see a drop down. Choose iPhone Simulator, then click the Run button.

Screen Shot 2013-08-29 at 16.40.16

Woop!

Book review – Instant Meteor Javascript Framework Starter

Leave a comment

Last year I started playing around with Meteor, a new javascript framework. I didn’t get much further than playing with and tweaking sample applications.

When it came time to start creating my own app in Meteor though, I was a bit lost. I didn’t really know where to start.

I was given a copy of Instant Meteor Javascript Framework Starter which I read over the weekend. The book was a good read – I especially enjoyed the opening chapters which covered what Meteor is and why it’s cool, better than the official Meteor docs cover.

It covered all the Meteor basics well, and I would recommend the book to anyone who wants to get started building their own app with Meteor. Reading it has gotten me excited about Meteor again!

RavenDB – Input string was not in a correct format

Leave a comment

In a RavenDB ASP.NET MVC app I was recently working on, I was constantly seeing good ol’ System.FormatException – “Input string was not in a correct format”.

My entities all use ints for their Ids.

After a while I noticed (via the RavenDB Management Console) that my entities had Ids like “tab/123″, but previously the Ids were like “tab-123″.

The problem turned out to be that I had accidentally removed this line while doing some refactoring:


documentStore.Conventions.IdentityPartsSeparator = "-";

Once I put that back in I stopped seeing the System.FormatException and all was right in the world.



Retrieve child items with an integer ID in a many-to-many with RavenDB

Leave a comment

I have a many to many relationship, like so

public class Movie
{
   public int Id { get; set; }
   public string Title { get; set; }
   public int[] ActorIds { get; set; }
   // etc
}

public class Actor
{
   public int Id { get; set; }
   public int Name { get; set; }
   // etc
}

When I load a Movie, I also want to load all of the Actors associated with that Movie.

This can be done using Raven's Load<T>(IEnumerable<System.ValueType> ids) method, and casting the int[] to an array of ValueType, like so:

var movie = RavenSession.Load<Movie>(movieId);
var actorIds = movie.TabIds.Cast<System.ValueType>();

var actors = RavenSession.Load<Actor>(actorIds).OrderBy(x => x.Name);

Regular expression replace in Visual Studio

1 Comment

I can never remember how to do replaces in Visual Studio using regular expressions, so here’s a quick example.

I’ve got 30 classes that implement BasePage. I want to change this:

public class VariationsPage : BasePage

to this:

public class VariationsPage : BasePage<VariationsPage>

The regex should find:

public class {.*} \: BasePage

and replace with:

public class \1 \: BasePage<\1>

Meteor todos sample – add buttons to move items up and down

Leave a comment

This is the sixth in a x part series about Meteor for beginners.

Let’s add the buttons to the UI first. I’ve decided to put them next to the delete button, so I will copy the html and css for the “destroy” class so that the UI is consistant.

<template name="todo_item">
  <li class="todo {{done_class}}">
    {{#if editing}}
      <div class="edit">
        <input id="todo-input" type="text" value="{{text}}" />
      </div>
    {{else}}
      <div class="move-up"></div>
      <div class="move-down"></div>
      <div class="destroy"></div>
      ...
#item-list .todo .destroy {
    cursor: pointer;
    position: absolute;
    margin-left: 50px;
    left: 5px;
    top: 15px;
    height: 20px;
    width: 20px;
}

#item-list .todo .move-up {
    cursor: pointer;
    position: absolute;
    left: 5px;
    top: 15px;
    height: 20px;
    width: 20px;
}

#item-list .todo .move-down {
    cursor: pointer;
    position: absolute;
    margin-left: 25px;
    left: 5px;
    top: 15px;
    height: 20px;
    width: 20px;
}

#item-list .todo .display, #item-list .todo .edit {
    margin-left: 80px;
    height: 100%;
    width: auto;
    float: left;
    padding-top: 18px;
    line-height: 1;
}

#item-list .todo:hover .move-up {
    background: url('/arrowup.png') no-repeat 0 0;
}

#item-list .todo .move-up:hover {
    background-position: 0 -20px;
}

#item-list .todo:hover .move-down {
    background: url('/arrowdown.png') no-repeat 0 0;
}

#item-list .todo .move-down:hover {
    background-position: 0 -20px;
}

PS. I spent longer making the up down arrow icons in an image editor than writing the code for this post!

Items in each todo list are currently sorted by their timestamp:

Template.todos.todos = function () {

  ...

  return Todos.find(sel, {sort: {timestamp: 1}});
};

I will continue to use the timestamp to control the sort order. When the up button is clicked, set the current item's timestamp to be 1ms less than the item above it.

Template.todo_item.events = {
  ...

  'click .move-up': function() {
    var todos = Template.todos.todos().fetch();
    var currentItemIndex = todoRanking(this, todos);

    if (currentItemIndex > 0) {
      var todoAboveMe = todos[currentItemIndex - 1];
      Todos.update(this._id, {$set: {timestamp: todoAboveMe.timestamp - 1}});
    }
  }
var todoRanking = function(todoItem, todoArray) {
  var ids = todoArray.map(function (todo) { return todo._id; });
  return ids.indexOf(todoItem._id);
};

We can do something similar to move an item down.

  'click .move-down': function() {
    var todos = Template.todos.todos().fetch();
    var currentItemIndex = todoRanking(this, todos);

    if (currentItemIndex < todos.length -1) {
      var todoBelowMe = todos[currentItemIndex + 1];
      Todos.update(this._id, {$set: {timestamp: todoBelowMe.timestamp + 1}});
    }
  }

See the code on github.

Meteor todos sample – remove all items

Leave a comment

This is the fifth in a x part series about Meteor for beginners.

Exercise 2: Add a Remove all items button

As usual, let’s add the button to the html first. I’m gonna stick it in the top frame next to the list of tags cos I can’t think of anywhere better to put it.

<template name="tag_filter">
  <div id="tag-filter" class="tag-list">
    <div class="label">Show:</div>
    {{#each tags}}
      <div class="tag {{selected}}">
        {{tag_text}} <span class="count">({{count}})</span>
      </div>
    {{/each}}
    <div class="label">
        <input type="button" class="clear-items" value="Clear all items" />
    </div>
  </div>
</template>

And now the code to handle the button click event:


Template.tag_filter.events = {
  'mousedown .tag': function () {
    if (Session.equals('tag_filter', this.tag))
      Session.set('tag_filter', null);
    else
      Session.set('tag_filter', this.tag);
  },
  'click .clear-items': function() {
    if (confirm('Are you sure you want to remove all todo items from the current list? This action cannot be undone.')) {
      var list_id = Session.get('list_id');
      if (!list_id)
        return;

      Todos.remove({list_id: list_id});
    }
  }
};

Easy!

See the code on github.

Meteor todos sample – friendly URLs

5 Comments

This is the fourth in a x part series about Meteor for beginners.

Introduction

I’ve been trying to get up to speed with Meteor lately. Since I don’t have any experience with nodejs it’s been a challenge.

I started by looking at the leaderboard sample, and then the todos sample. At the end of the video the author lays down a challenge – to make the URLs friendly. So instead of http://localhost:3000/bbbeec7c-6749-400b-bc45-4ed744e010b7 it should be http://localhost:3000/Languages. In order to do that I needed to understand how routing works.

When you click on a todo list in the left, this code fires:

Template.lists.events = {
  'mousedown .list': function (evt) { // select list
    Router.setList(this._id);
  },

which calls:

var TodosRouter = Backbone.Router.extend({
  routes: {
    ":list_id": "main"
  },
  main: function (list_id) {
    Session.set("list_id", list_id);
    Session.set("tag_filter", null);
  },
  setList: function (list_id) {
    this.navigate(list_id, true);
  }
});

The setList function calls navigate, which is Backbone.js's router function to save the current location in the browser's history. The "true" parameter also tells the browser to navigate to the url, so if list_id = "1234" the browser will navigate to i.e. localhost:3000/1234.

According to the routes defined here

var TodosRouter = Backbone.Router.extend({
  routes: {
    ":list_id": "main"
  },

if I navigate to localhost:3000/1234, then "1234" will be passed to the "main" function as the "list_id" parameter. Which takes us to:

var TodosRouter = Backbone.Router.extend({
  routes: {
    ":list_id": "main"
  },
  main: function (list_id) {
    Session.set("list_id", list_id);
    Session.set("tag_filter", null);
  },
  setList: function (list_id) {
    this.navigate(list_id, true);
  }
});

OK, so the only thing that the "main" function does is set two Session variables. What effect does that have? Time to look at some html.

client/todos.html:

<template name="todos">
  {{#if any_list_selected}}
  <div id="items-view">
    <div id="new-todo-box">
      <input type="text" id="new-todo" placeholder="New item" />
    </div>
    <ul id="item-list">
      {{#each todos}}
        {{> todo_item}}
      {{/each}}
    </ul>
  </div>
  {{/if}}
</template>

That there is a Handlebars template, with name="todos". Interestingly, it has a "#each todos". The data for that is retrieved by a helper function called "todos" (on the Template also called "todos"), i.e. this:

Template.todos.todos = function () {
  // Determine which todos to display in main pane,
  // selected based on list_id and tag_filter.

  var list_id = Session.get('list_id');
  if (!list_id)
    return {};

  var sel = {list_id: list_id};
  var tag_filter = Session.get('tag_filter');
  if (tag_filter)
    sel.tags = tag_filter;

  return Todos.find(sel, {sort: {timestamp: 1}});
};

This template (like all Meteor templates) reactively monitors the Session and detects that the value for Session.get('list_id') has changed, so it runs again and returns the todo items to be rendered. Each todo item is then rendered by another Handlebars template called todo_item , as per the {{> todo_item}} in the html.

In summary then,

  1. Todo list link is clicked in the left pane, calls TodosRouter.setList(list_id).
  2. TodosRouter.setList navigates to ~/list_id
  3. Router.main sets Session[list_id] variable.
  4. The template helper "todos" detects Session[list_id] has changed so it re-runs.
  5. The Handlebars template named "todos" is re-rendered with the result of the "todos" template helper.

So how do we make the URLs friendly?

Now that we understand how routing works in Meteor, we can take the TodosRouter shown above and change:

  1. TodosRouter.setList(list_id) to TodosRouter.setList(list_name)
  2. TodosRouter.setList should navigate to ~/list_name
  3. Router.main can lookup the correct list_id from the list_name and set the Session[list_id] as before.

So

var TodosRouter = Backbone.Router.extend({
  routes: {
    ":list_name": "main"
  },
  main: function (list_name) {
    var list = Lists.findOne({name: list_name});
    if (list)
      Session.set("list_id", list._id);
    Session.set("tag_filter", null);
  },
  setList: function (list_name) {
    this.navigate(list_name, true);
  }
});

We also need to change all the code which calls setList():

Template.lists.events = {
  'mousedown .list': function (evt) { // select list
    Router.setList(this.name);
  },
Meteor.subscribe('lists', function () {
  if (!Session.get('list_id')) {
    var list = Lists.findOne({}, {sort: {name: 1}});
    if (list)
      Router.setList(list.name);
  }
});
Template.lists.events[ okcancel_events('#new-list') ] =
  make_okcancel_handler({
    ok: function (text, evt) {
      var id = Lists.insert({name: text});
      Router.setList(text);

Finally, for cosmetic reasons, we should change the "lists" template so that the html that's rendered for the todo list links has the correct href attribute - so that when the user hovers over the link they see the new friendly url.

<a class="list-name {{name_class}}" href="/{{name}}">
  {{name}}
</a>


See the source code on github.

Meteor leaderboard sample exercise three

1 Comment

This is the third in a x part series about Meteor for beginners.

Exercise 3a: Remove a scientist from the leaderboard

This should be easy. First, let’s add a button.

<template name="leaderboard">

  ...

  {{#if selected_name}}
  <div class="details">
    <div class="name">{{selected_name}}</div>
    <input type="button" class="inc" value="Give 5 points" />
    <input type="button" class="delete" value="Delete" />
  </div>
  {{/if}}

  ...
</template>

And now the event to fire when the button is clicked:

  Template.leaderboard.events = {

    ...

    'click input.delete': function() {
      if (confirm('Are you sure you want to delete the player?')) {
        Players.remove(Session.get("selected_player"));
      }
    }

N.B. the remove() function accepts either a selector i.e. Players.remove({_id: Session.get("selected_player")}), or a string (which is the _id) as its first argument.

Exercise 3b: Add a new scientist to the leaderboard

Let's add a new "addPlayer" template to the html:

<template name="addPlayer">
    <div>
        <div>Add a new player:</div>
        <span class="name">Name:</span>
        <input type="text" id="playerName" />
        <span class="score">Score:</span>
        <input type="text" id="playerScore" />
        <input type="button" class="add" value="Add player" />
    </div>
</template>

And now render it after the leaderboard template:

<body>
  <div id="outer">
    {{> leaderboard}}
    {{> addPlayer}}
  </div>
</body>

And now lets add template event code which will fire when the "Add player" button is clicked:


  Template.player.events = {
    'click': function () {
      Session.set("selected_player", this._id);
    }
  };

  Template.addPlayer.events = {
    'click input.add': function () {
      // todo - add validation
      Players.insert({name: playerName.value, score: Number(playerScore.value)});
    }
  };
}

Browse the code on Github.

Meteor leaderboard sample exercise two

1 Comment

This is the second in a x part series about Meteor for beginners.

Exercise 2: Add a button to randomise all players scores

First, let’s add the button to the bottom of the leaderboard template.
leaderboard.html:

<template name="leaderboard">

  ...

  <div>
      <input type="button" class="randomise" value="Randomise" />
  </div>
</template>

The meteor sample already has a formula to generate a random score which is called on startup if the database is empty. So let's refactor that into a function so that we can reuse it.

//
var randomScore = function() {
  return Math.floor(Math.random()*10)*5;
}

// On server startup, create some players if the database is empty.
if (Meteor.is_server) {
  Meteor.startup(function () {
    if (Players.find().count() === 0) {
      var names = ["Ada Lovelace",
                   "Grace Hopper",
                   "Marie Curie",
                   "Carl Friedrich Gauss",
                   "Nikola Tesla",
                   "Claude Shannon"];
      for (var i = 0; i < names.length; i++)
        Players.insert({name: names[i], score: randomScore()});
    }
  });
}

Now all we need to do is add an event to handle the button click which will do the work:

  Template.leaderboard.events = {

    ...

    'click input.randomise': function() {
      Players.find({}).forEach(function(player) {
        Players.update(player, {$set: {score: randomScore()}});
      });
    }
  };

Browse the code at github.

Older Entries

Follow

Get every new post delivered to your Inbox.
